AZS#36 PT WS ZWS Glass Kiln AZS Brick High Temperature Fire Brick

ZHENGZHOU CAIHUA KILN MASONRY INSTALLATION CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap AZS#36 PT WS ZWS Glass Kiln AZS Brick High Temperature Fire Brick from wholesalers

    Buy cheap AZS#36 PT WS ZWS Glass Kiln AZS Brick High Temperature Fire Brick from wholesalers
    • Buy cheap AZS#36 PT WS ZWS Glass Kiln AZS Brick High Temperature Fire Brick from wholesalers

    AZS#36 PT WS ZWS Glass Kiln AZS Brick High Temperature Fire Brick

    Ask Lasest Price
    Brand Name : CH Refractories
    Model Number : AZS
    Certification : ISO
    Price : USD 500-1000 per Ton
    Payment Terms : L/C, T/T
    Supply Ability : 5000 Ton per month
    Delivery Time : 5-15 working days
    • Product Details
    • Company Profile

    AZS#36 PT WS ZWS Glass Kiln AZS Brick High Temperature Fire Brick

    AZS#36 PT WS ZWS Glass Kiln Applied Fused Cast AZS Block High Corrosion Resistance Glass Melting Brick

    Glass Kiln Applied Fused Cast AZS Block

    Glass Kiln Applied Fused Cast AZS Block is also named AZS brick. It is based on three chemical components of the Al2O3-ZrO2-SiO2 ternary phase diagram and widely used for glass kiln. The glass kiln brick is arranged according to the order of its contents. Al2O3 takes A, ZrO2 takes Z, and SiO2 takes S. The national standard uses this abbreviation. For example, No.33 cast zirconia corundum brick, abbreviated as AZS-33#, No. 36 cast zirconia corundum brick, abbreviated as AZS-36#, No. 41 cast zirconia corundum brick, abbreviated as AZS-41#.
    AZS-33# Brick to prevent contamination of glass liquid is particularly superior, it causes stones in glass, bubbles and basic glass phase precipitation trend is very small. It is suitable for the upper structure of the glass melting pool, the wall brick of the working pool, the paved brick and the material channel.


    CH Refractories has exported the fused AZS glass kiln bricks to middle east, Aisa, Africa, Europe.,etc over 20 countries, and got the long term cooperation with our customers, welcome to contact us discuss the cooperation!

    Applications of Zirconia Corundum(AZS) Brick:
    Widely be used for linings of furnace in glass industries.


    Items

    Unit

    Index



    AZS33-Y

    AZS36-Y

    AZS41-Y

    Chemical composition

    Al2O3

    %

    ≤50

    ≤42

    ≤40

    ZrO2

    %

    32-36

    35-40

    40-44

    1650

    SiO2

    %

    ≤16

    ≤14

    ≤13

    Na2O

    %

    ≤1.45

    ≤1.45

    ≤1.3

    Fe2O3+TiO2+CaO+MgO+Na2O+K2O

    %

    ≤2

    ≤2

    ≤2

    Fe2O3+TiO2

    %

    ≤0.3

    ≤0.3

    ≤0.3

    Bulk density

    g/cm3

    ≥3.75

    ≥3.8

    ≥3.95

    Apparent porosity

    %

    ≤1.5

    ≤1

    ≤1

    Static anti-corrosion rate of glass liquid(ordinary soda-lime glass, 1500℃*36h)

    Mm/24h

    ≤1.5

    ≤1.4

    ≤1.3

    Initial exudation temperature of glass phase

    ≥1400

    ≥1400

    ≥1400

    Bubble release proportion (ordinary soda-lime glass, 1300℃*10h)

    %

    ≤2

    ≤1.5

    ≤1

    Glass phase seepage discharge(1500℃*4h)

    %

    ≤2

    ≤3

    ≤3

    Working temperature

    ≥1650

    ≥1650

    ≥1650


    Advantages of CH series Glass Kiln Applied Fused Cast AZS Block:
    Erosion resistance. Ultra low apparent porosity
    High strength and high compression resistance
    Thermal shock resistance and erosion resistance
    Performance in high temperature, good thermal conductivity
    Free sampleFree construction guidance free 3D design
    Customerize mould according to different size requirements for free
    Caihua refractory company manufactured azs bricks with very competitive price comparing with other suppliers in China.
